• (4) air registers w/positive shut-off
• 11.5" day/night mirror
• Auxiliary pwr point
• Black vinyl steering wheel
• Color-keyed carpet full-floor covering
• Color-keyed cloth sun visors-inc: LH strap, RH mirror
• Color-keyed instrument panel w/dual cupholders/glove box/ashtray/cigar lighter
• Color-keyed molded cloth headliner
• Color-keyed molded door trim panel-inc: soft armrest, grab handle,reflector, upper vinyl insert, carpeted map pocket
• Color-keyed scuff plates
• Dual color-keyed coat hooks
• Dual dome lamps w/time delay off
• Dual map lights
• Electronic AM/FM stereo w/cassette-inc: digital clock, (4) speakers
• Forward-folding rear flight bench seat
• Front passenger assist handle
• Grab handles mounted over rear doors
• Gray fabric back panel cover
• Inside hood release
• Instrumentation-inc: tachometer, trip odometer, voltmeter, oil pressure/ coolant temp/fuel gauges, indicator lights
• Underhood service light

• (2) front tow hooks
• 172" WB
• 2-speed transfer case
• 3.73 axle ratio
• 4-pin trailer tow wiring connector
• 72 amp/hr (650 CCA) maintenance-free battery
• 95 amp alternator
• Four wheel drive
• Front stabilizer bar
• HD gas shock absorbers
• Manual locking front hubs
• Mono-beam front axle
• Pwr steering

• Anti-lock braking system
• Color-keyed safety belts w/front seat adjustable D-rings
• Driver & front passenger air bags
• Dual-note horn

7.3L (444) DI V8 TURBO-DIESEL ENGINE

• 130 amp alt
• dual 78 amp/hr batteries
• engine block heater
• exhaust back pressure valve

• Four Wheel Drive
• Tow Hooks
• Dual Rear Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Dual Rear Wheels
• Steel Wheels
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Intermittent Wipers
• Rear Bench Seat
• AM/FM Stereo
• Cassette
• Power Outlet
• Front Reading Lamps
• ABS
• Driver Air Bag
• Passenger Air Bag

• Brakes
• Brake ABS System: 4-Wheel
• Brake Type: Power
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.03 x
• Rear Brake Rotor Diam x Thickness (in): 12.83 x
• Cargo Area Dimensions
• Cargo Box (Area) Height (in): 20.0
• Cargo Box Length : Floor (in)
• Cargo Box Width : Floor (in)
• Cargo Box Width : Top, Rear (in)
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume (ft³): 77.7
• Tailgate Width (in): 65.0
• Cooling System
• Total Cooling System Capacity (qts): 30.6
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 130
• Maximum Alternator Watts: 1950
• Exterior Dimensions
• Cab to Axle (in): 56.2
• Front Bumper to Back of Cab (in): 153.6
• Ground to Top of Load Floor (in): 37.3
• Height, Overall (in): 80.6
• Length, Overall w/o rear bumper (in): 257.6
• Overhang, Front (in): 37.4
• Overhang, Rear w/o bumper (in): 47.8
• Wheelbase (in): 172.4
• Width, Max w/o mirrors (in): 95.5
• Frame
• Frame Type: Ladder-Type
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 38
• Fuel Tank Location: Midship
• Interior Dimensions
• Front Head Room (in): 41.4
• Front Hip Room (in): 67.4
• Front Leg Room (in): 40.7
• Front Shoulder Room (in): 68.0
• Passenger Capacity: 6
• Second Head Room (in): 41.0
• Second Hip Room (in): 67.3
• Second Leg Room (in): 42.5
• Second Shoulder Room (in): 68.0
• Steering
• Steering Ratio (:1), On Center: 17.1
• Steering Type: Power
• Turning Diameter - Curb to Curb (ft): 61.7
• Turning Diameter - Wall to Wall (ft): 64.3
• Summary
• Body Code: 172" WB
• Body Style: Crew Cab 8'
• Vehicle Name: Ford Super Duty F-350 DRW
• Suspension
• Axle Capacity - Front (lbs): 5200
• Axle Capacity - Rear (lbs): 9750
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Axle Type - Front: Dana Monobeam
• Axle Type - Rear: Ford Full-Floating
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Spring Capacity - Front (lbs): 4800
• Spring Capacity - Rear (lbs): 8250
• Suspension Type - Front: Single-Stage Leaf
• Suspension Type - Rear: Multi-Leaf
• Tires
• Front Tire Capacity (lbs): 2778
• Front Tire Order Code: T35
• Front Tire Size: LT235/85R16E
• Rear Tire Capacity (lbs): 2778
• Rear Tire Order Code: T35
• Rear Tire Size: LT235/85R16E
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 3575
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 14300
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1000
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10000
• Weight Information
• Curb Weight - Front (lbs): 3792
• Curb Weight - Rear (lbs): 2699
• Gross Axle Wt Rating - Front (lbs): 4800
• Gross Axle Wt Rating - Rear (lbs): 8250
• Gross Combined Wt Rating (lbs): 20,000
• Gross Vehicle Weight Rating Cap (lbs): 11,200
• Wheels
• Front Wheel Material: Steel
• Front Wheel Size (in): 16 x 6.0
• Rear Wheel Material: Steel
• Rear Wheel Size (in): 16 x 6.0
